Experience The BossVac Difference
Designed for performance, engineered for uptime, and delivered without corporate B.S.
Spec’d for You, Not the Masses
Get what you need—no bloated features, no overpriced fluff. Every BossVac trailer is built to your spec.
Rock-Solid Reliability
Fewer failure points. Field-proven design. BossVac stays on the job when others fall apart.
No Junk Parts. Ever.
We spec quality, serviceable components—not dealer-only garbage. You can fix it without a service call.
Fast Lead Times
Get to work without waiting 6 months. Most builds are ready fast—or already on the lot.
Engineered for Real-World Use
Simple controls, rugged systems, zero nonsense. Built by people who’ve done the work.
HYDROVAC TRAILER SPEC SHEETS
Trailer Specs
| Trailer | BV-1000 | BV-500 | BV-350 |
|---|---|---|---|
| Length | 21.6 Feet | 21.6 Feet | 21.6 Feet |
| Width | 98.5 Inches | 98.5 Inches | 98.5 Inches |
| Height | 7.6 Feet | 7.6 Feet | 7.6 Feet |
| Weight (Empty)* | 10,300 lb* | 7,000 lb* | 1500 lb* |
| GVWR* | 20,000 lb* | 14,000 lb* | 20,000 lb* |
| Hitch | Bumper or Gooseneck | Bumper or Gooseneck | Bumper or Gooseneck |
| Trailer Axles | (2) 7,000 lb Axles | (2) 7,000 lb Axles | (2) 7,000 lb Axles |
Engine Specs
| Engine | BV-1000 | BV-500 | BV-350 |
|---|---|---|---|
| Horsepower* | 74* | 36.8* | 5* |
| Make | Yanmar | Yanmar | Yanmar |
| Model | Tier 4 | Tier 4 | Tier 4 |
| Fuel Tank Capacity | 17 Gallons | 17 Gallons | 17 Gallons |
Water Tank & Pump
| Water Tank & Pump | BV-1000 | BV-500 | BV-350 |
|---|---|---|---|
| Water Tank Capacity | 400 Gallons | 400 Gallons | 400 Gallons |
| Number of Tanks | 2 | 2 | 2 |
| High Pressure Pump Flow Rate | 4 GPM | 4 GPM | 4 GPM |
| High Pressure Pump PSI | 4,000 PSI | 4,000 PSI | 4,000 PSI |
Spoil Tank
| Spoil Tank | BV-1000 | BV-500 | BV-350 |
|---|---|---|---|
| Capacity | 800 Gallons | 800 Gallons | 800 Gallons |
| Door Type | Hydraulic / 8 Wing Nut Manual Lock | Hydraulic / 8 Wing Nut Manual Lock | Hydraulic / 8 Wing Nut Manual Lock |
| Wash | Internal Wash Out System | Internal Wash Out System | Internal Wash Out System |
| Tank Wall Thickness | 1/4" | 1/4" | 1/4" |
| Tank Lift Type | Hydraulic to 70° Tilt | Hydraulic to 70° Tilt | Hydraulic to 70° Tilt |
Vacuum & Blower
| Vacuum & Blower | BV-1000 | BV-500 | BV-350 |
|---|---|---|---|
| Filters | 5 Micron | 5 Micron | 5 Micron |
| Hose Length | 30 Feet | 30 Feet | 30 Feet |
| Hose Width | 3 Inches | 3 Inches | 3 Inches |
| Weight Empty | 7,000 lb | 7,000 lb | 7,000 lb |
| Vacuum Type | Tri-Lobe | Tri-Lobe | Tri-Lobe |
| Vacuum* | 1,000 CFM* | 500 CFM* | 250 CFM* |
| Vacuum Mercury | 27" | 24" | 27 Inches |
HYDROVAC TRAILER SPEC SHEETS
See What Powers Each BossVac Trailer
Compare BossVac Trailers
BV-350
Lightweight - Low Hassle
BV-500
Balanced for Everyday Use
BV-1000
Max Power - Max Payload
Engine
BV-350
BV-500
BV-1000
Horsepower*
5 HP
36.8 HP
74 HP
Make
Yanmar
Yanmar
Yanmar
Model
Tier 4
Tier 4
Tier 4
Fuel Tank Capacity
17 Gallons
17 Gallons
17 Gallons
Vacuum & Blower
BV-350
BV-500
BV-1000
Filters
5 Micron
5 Micron
5 Micron
Hose Length
30 Feet
30 Feet
30 Feet
Hose Width
3 Inches
3 Inches
3 Inches
Vacuum Type
Tri-Lobe
Tri-Lobe
Tri-Lobe
Vacuum*
350 CFM
500 CFM
1,000 CFM
Vacuum Mercury
20 Inches
24 Inches
27 Inches
Water Tank & Pump
BV-350
BV-500
BV-1000
Water Tank Capacity
400 Gallons
400 Gallons
400 Gallons
Number of Tanks
2
2
2
High Pressure Pump Flow Rate
4 GPM
4 GPM
4 GPM
High Pressure Pump PSI
4,000 PSI
4,000 PSI
4,000 PSI
Spoil Tank
BV-350
BV-500
BV-1000
Capacity
800 Gallons
800 Gallons
800 Gallons
Door Type
Hydraulic / 8 Wing Nut Manual Lock
Hydraulic / 8 Wing Nut Manual Lock
Hydraulic / 8 Wing Nut Manual Lock
Wash
Internal Wash Out System
Internal Wash Out System
Internal Wash Out System
Tank Wall Thickness
1/4"
1/4"
1/4"
Tank Lift Type
Hydraulic to 70° Tilt
Hydraulic to 70° Tilt
Hydraulic to 70° Tilt
Trailer Specs
BV-350
BV-500
BV-1000
Length
21.6 Feet
21.6 Feet
21.6 Feet
Width
95.5 Inches
95.5 Inches
95.5 Inches
Height
7.6 Feet
7.6 Feet
7.6 Feet
Weight (Empty)*
5,000 lb
7,000 lb
10,300 lb
GVWR*
10,000 lb
14,000 lb
20,000 lb
Hitch
Bumper or Gooseneck
Bumper or Gooseneck
Bumper or Gooseneck
Trailer Axles
(2) 7,000 lb Axles
(2) 7,000 lb Axles
(2) 7,000 lb Axles
You Spec It — We Build It
Built Your Way — No Compromises
Choose your tank size, blower, hitch, and layout
Configure systems to match your workflow
Add only what you need — nothing you don’t
No dealer-only electronics or locked-down software
Designed for real crews, not corporate specs
BossVac builds to fit your job, your team, and your bottom line.
Why Contractors Trust BossVac
🔧 Performance
Tri-lobe Blowers vs. Dual-lobe:
BossVac uses tri-lobe blowers for higher vacuum performance, quieter operation, longer lifespan, and better energy efficiency—unlike competitors still using outdated dual-lobe systems.
Real Workhorse Power:
Whether you’re pulling 500 or 1,000 CFM, BossVac trailers dig deeper and faster with fewer breakdowns thanks to simplified systems and raw horsepower.
Purpose-Built, Not Overbuilt:
No fragile sensors or dealer-only electronics. Every system is designed to enhance function, not complicate it.
🌎 Environment & Safety:
Hydro Excavation Benefits:
More precise than manual digging, safer around utilities, and far more environmentally friendly than mechanical methods.
🛠️ Reliability & Maintenance
BossVac Uptime Assurance:
Downtime kills profit. Our trailers use premium parts sourced for performance and availability—so you don’t have to wait weeks or pay dealer-only labor just to keep working.
Common-Sense Engineering:
No proprietary software. No over-engineered failure points. Just dependable gear that stays on the job.
⚡ Speed, Customization, Delivery:
Quick Ship, Fully Custom:
Most trailers are ready to go or built to spec fast—no 6-month waitlists, no corporate red tape. Need a different tank, nozzle setup, or trailer layout? We’ll build it.
Made in Oklahoma:
Every BossVac trailer is made in the U.S.A. by people who understand what it means to work for a living. It’s not outsourced. It’s overbuilt.
Performance 🔧
Tri-lobe Blowers vs. Dual-lobe:
BossVac uses tri-lobe blowers for higher vacuum performance, quieter operation, longer lifespan, and better energy efficiency—unlike competitors still using outdated dual-lobe systems.
Real Workhorse Power:
Whether you’re pulling 500 or 1,000 CFM, BossVac trailers dig deeper and faster with fewer breakdowns thanks to simplified systems and raw horsepower.
Purpose-Built, Not Overbuilt:
No fragile sensors or dealer-only electronics. Every system is designed to enhance function, not complicate it.
Reliability & Maintenance 🛠️
BossVac Uptime Assurance:
Downtime kills profit. Our trailers use premium parts sourced for performance and availability—so you don’t have to wait weeks or pay dealer-only labor just to keep working.
Common-Sense Engineering:
No proprietary software. No over-engineered failure points. Just dependable gear that stays on the job.
Environment & Safety 🌎
Hydro Excavation Benefits:
More precise than manual digging, safer around utilities, and far more environmentally friendly than mechanical methods.
Speed, Customization, Delivery⚡
Quick Ship, Fully Custom:
Most trailers are ready to go or built to spec fast—no 6-month waitlists, no corporate red tape. Need a different tank, nozzle setup, or trailer layout? We’ll build it.
Made in Oklahoma:
Every BossVac trailer is made in the U.S.A. by people who understand what it means to work for a living. It’s not outsourced. It’s overbuilt.
